Quantum VS-NVR Series
High-performance, cost-effective video recording servers.
Quantum offers a broad portfolio of network video recording servers to meet the needs of any surveillance environment, from a few cameras to hundreds of cameras. Each product is designed with the latest hardware to achieve the best performance at the best price, and to maximize the useful life of the products.
The VS-NVR series is available in a variety of form factors, including mini-tower, 1U rack mount, and an ultra-dense 4U 60-bay rack mount server for recording and retaining footage from hundreds of cameras for months or years.
Every product is backed by Quantum’s global support organization, providing installation and support 24x7x365 to tens of thousands of customers around the world.
Featured Benefits
High Performance
Designed with the latest hardware and operating systems to maximize the number of cameras each product can support.
Cost-Effective
Each VS-NVR product was designed and specified to achieve the best performance at the lowest cost.
Easy to Deploy and Maintain
VS-NVR series products are pre-certified and pre-installed with the operating system so you can connect it to your network and start to record in minutes.
Latest Generation Hardware
Quantum VS-Series products use the latest generation hardware resulting in extended lifecycles for your projects.
Technical Specifications
| Appliance | VST102-NVR | VST104-NVR | VS1004-NVR | VS4160-NVR |
|---|---|---|---|---|
| Use Case* | NVR for <30 cameras | NVR for <30 cameras with additional space for longer retention of video | NVR for <150 cameras | NVR for 400+ cameras and longer retention of video |
| Form Factor | Mini-Tower | Mini-Tower | 1U Rack Mount | 4U Rack Mount |
| Boot Drives | 1x 256 GB NVMe M.2 | 1x 256 GB NVMe M.2 | 1x 256 GB NVMe M.2 | 2x SSD (480 GB each) |
| Base # HDDs | 2 | 4 | 2 | 36 |
| Max # HDDs | 2 | 4 | 4 | 60 |
| Max Raw Capacity (TB) - not incl. boot drives | 24 | 48 | 64 | 960 |
| Max # of SSDs (non-boot) | N/A | N/A | N/A | N/A |
| RAM | 8 GB | 8 GB | 16 GB | 128 GB |
| CPU | Core i5-8500 (6C/6T, 3 GHz, 9M Cache, 65 W, 630 Graphics) |
Core i5-8500 (6C/6T, 3 GHz, 9M Cache, 65 W, 630 Graphics) |
E-2176G (6C/12T, 3.70 GHz, 12M Cache, 80 W, P630 Graphics) |
2 Xeon Gold 6230 (20C/40T, 2.1 GHz, 27.5M Cache, 125 W) |
| Avg CPU Passmark Score (from cpubenchmark.net) | 11830 | 11830 | 15582 | 24559 (per CPU) |
| Operating System | Windows 10 IoT Enterprise | Windows 10 IoT Enterprise | Windows 10 IoT Enterprise | Windows Server 2019 Standard Edition |
| Power Supply | 1x250 W 80 PLUS® Certified Bronze with IEC320 C14 receptacle | 1x250 W 80 PLUS Certified Bronze with IEC320 C14 receptacle | 1x350 W 80 PLUS Certified Platinum with IEC320 C14 receptacle | 2x2000 W Redundant, Hot Swap, 80 PLUS Certified Titanium, each with IEC320 C14 receptacle |
| Display Connections | 1 VGA D-Sub Connector port, 1 DVI-D port, 1 DisplayPort, 1 HDMI - up to 3 Independent Displays | 1 VGA D-Sub Connector port, 1 DVI-D port, 1 DisplayPort, 1 HDMI - up to 3 Independent Displays | 1 VGA D-Sub Connector port, 1 DVI-D port, 2 DisplayPorts - up to 3 Independent Displays | 1 VGA D-Sub Connector port |
| Network Connections | 2x1GbE | 2x1GbE | 2x1GbE | 4x10GbE |
| Dimensions (hxwxd) | 9.45" (240 mm) x 8.27" (210 mm) x 11" (279 mm) | 9.45" (240 mm) x 8.27" (210 mm) x 11" (279 mm) | 1.7" (43 mm) x 17.2" (437 mm) x 19.8" (483 mm) | 7" (178 mm) x 17.2" (437 mm) x 30.2" (767 mm) |
| Warranty | 1 yr or 3 yrs NBD (CRU or Onsite) | 1 yr or 3 yrs NBD (CRU or Onsite) | 3 yrs NBD (CRU or Onsite) | 3 yrs NBD (CRU or Onsite) |
*Supported # of cameras assumes 1080p cameras @ 30 fps using H.264.
